0.8mm Pitch Male Straight Connector SMT PA9T UL94V-0 Board To Board D Type

Product Categories
WCON ELECTRONICS ( GUANGDONG) CO., LTD
Contact Now

0.8mm Pitch Male Straight Connector SMT PA9T UL94V-0 Board To Board D Type

Brand Name : WCON

Model Number : 3614-PXXX-XXXXXR01

Certification : UL/CUL/SGS/ROHS

Place of Origin : China

MOQ : 1000pcs

Price : Negotiation

Payment Terms : T/T

Supply Ability : 800000kpcs

Delivery Time : 15-25Day

Packaging Details : Reel

Sample : Free

Gender : Female

Pitch : 0.8mm

Withstand Voltage : 500V AC/DC

Contact Material : Phosphor Bronze

Contact Now

0.8mm Pitch Male 180° SMT PA9T UL94V-0 Board to Board Connector D Type



Current Rating 0.5AMP
Contact Resistance 65mΩ Max
Withstand Voltage 250V AC/Minute
Insulation Resistance 100mΩ Min
Operation Temperature ﹣20℃ to +105℃
Contact Material Phosphor Bronze
Standard LCP+30%GF
Contact  Plating Au Or Sn Over Ni



Product name: .0.8MM board to board Connector

1. product characteristics: in the current connector transmission capacity of the strongest; a wide range of use, environmental protection, high temperature resistance, fire prevention, antioxidation, electrical conductivity, precision strong connection.

2. material: UL94V-0, PA9T+30%GF, copper alloy material

3. scope of application: power system, communication network, financial manufacturing, elevator, industrial automation, medical equipment, office equipment, home appliances, military manufacturing industry.



0.8mm Pitch Male Straight Connector SMT PA9T UL94V-0 Board To Board D Type

0.8mm Pitch Male Straight Connector SMT PA9T UL94V-0 Board To Board D Type



0.8mm Pitch Male Straight Connector SMT PA9T UL94V-0 Board To Board D TypeDrawing:Board To Board 3614-PXXX-XXXXXR01.pdf
