Dual Row 3.0mm Housing Wire To Board Connector LCP black ROHS matching with WF3001-T

Name: Dual Row 30mm Housing Wire To Board Connector LCP black ROHS matching with WF3001T
Brand: WCON
Price: 1 USD

Buy cheap Dual Row 3.0mm Housing Wire To Board Connector LCP black ROHS matching with WF3001-T product

Brand Name : WCON

Model Number : WF3001-2H03B01

Certification : UL/SGS/ROHS

Place of Origin : China

MOQ : 1000pcs

Price : negotiation

Payment Terms : T/T

Supply Ability : 800000PCS

Delivery Time : 15~25Day

Packaging Details : Tray

Insulator Material : Polyester(UL94V-0)

Sandard : LCP

Use With : WF3001-T(Crimple Terminal)

Mated With : WF3001-Wafer

pitch : 3.00mm

port : hong kong

type : dual row

color : black

Contact Now

3.0mm Dual Row Housing Wire To Board Connector mini wire connectors

1.Item name: Wafer connector

2.product features: it makes the design and production process more convenient, more flexible, reduce 3.production and maintenance costs, easy maintenance, easy to upgrade, improve the flexibility of the design

4.product material: (UL94V-0) PA9T, PA6T, PA46, PA66, etc.

5.scope of application: used in computer and peripheral equipment, communication products, test instruments, consumer electronics products, automotive industry, medical electronic products, the production of military and aerospace industry in which the device connecting the two active devices, current or signal transmission.

Rated Current	5.0AMP
Contact Resistance	10mΩ Max
Withstand Voltage	1500V AC/DC
Insulation Resistance	1000mΩ Min
Operation Temperature	﹣25℃ to +85℃
Pin Material	Brass
Contact Plating	Au or Sn over Ni
Insulator Material	Polyester(UL94V-0)
Standard	LCP

Dual Row 3.0mm Housing Wire To Board Connector LCP black ROHS matching with WF3001-T

Drawing:WF3001-2HXXB01.pdf
